Specification For Aluminum Air Grille

• Fitting for steel panels, woodcore or calcium sulphate panels.
• 600mmx600mm or 24”x24”.
• Panel weight: 10kg/pc
• Panel height: 50mm with damper
• The stringer width requirement: apply the same stringer as what for panels.
• aluminum extruded structure
• 68% open area
• Available with coatings
• Bottom adjustable damper available
• Removable with portable lifting device

Loading Performance Chart(Cisca Test Procedures)

system

Static loads

Rolling loads

Impact loads

Panel

Understructure

Concentrated loads

Uniform Loads

Ultimate Loads

10 Passes

10,000 Passes



68% air grille



5,00lbs

6.75kn/sqm

1000lbs

300lbs

200lbs

100lbs
